Best Quality 2MP HD Wide Dynamic Range Fov 100 Degree AR0230 Sensor CMOS Camera Module With Beauty Function

Module No.

HBVCAM-1812 S1.0

Module Size

38mm × 38mm × 18.24mm±0.5MM

Temperature (Operation)

-20°C to 70°C

Temperature (Stable Image)

0°C to 50°C

Assembly technique

SMT (ROSH)

Focus

Fixed

Object distance

30CM-infinity

Resolution

600LW/PH (Center)

PCB printing ink

black

interface

USB 2.0

Power suuply

USB bus power

supply voltage

DC 5V±5%

Maximum Power consumption

1100mW

Operating system request

Win XP/win 7、8 / vista /android 4.0/ mac /Linux with uvc

Sensor

AR0230 (1/2.7” )

Seneor Package

CSP,Bare Die

Maximum resolution

1920*1080

Sensitivity

4.0V /（lux-sec）

Pixel Size

3.0µm x 3.0µm

MJPEG 640x480 30FPS / YUY2 640x480 30FPS
MJPEG 800x600 30FPS / YUY2 800x600 10FPS
MJPEG 1024x768 30FPS / YUY2 1024x768 10FPS
MJPEG 1280x720 30FPS / YUY2 1280x720 10FPS
MJPEG 1920x1080 30FPS / YUY2 1920x1080 5FPS

Output Formats

YUY2/MJPEG

Microphone

Support

FOV

100°

Certifications

FCC/CE/ROSH
