High Quality 2MP Fixed Focus CMOS IMX291 Sensor camera module 4PIN Telephoto lens zoom camera module

Module No.

HBVCAM-1917HD V33

Module Size

38mm × 38mm × 37.7mm±0.5MM

Temperature (Operation)

-30°C to 70°C

Temperature (Stable Image)

0°C to 50°C

Assembly technique

SMT (ROSH)

Focus

Fixed

Object distance

30CM-infinity

Resolution

600LW/PH (Center)

PCB printing ink

Black

interface

USB 2.0

Power suuply

USB bus power

supply voltage

DC 5V±5%

Maximum Power consumption

1000 mW

Operating system request

Win XP/win 7、8 / vista /android 4.0/ mac /Linux with uvc

Sensor

IMX291 (1/2.8” )

Seneor Package

CSP,Bare Die

Maximum resolution

1920*1080

Sensitivity

3300mV /（lux-sec）

Pixel Size

2.9µm x 2.9µm

MJPEG 320x240 30FPS / YUY2 320x240 30FPS
MJPEG 640x480 30FPS / YUY2 640x480 30FPS
MJPEG 1280x720 30FPS /
MJPEG 1920x1080 30FPS /

Output Formats

YUY2/MJPEG

Microphone

Support

FOV

71°

Certifications

FCC/CE/ROSH
