Module No.

HBVCAM-5M2134 V11

Module Size

38mm × 38mm × 25mm±0.5MM

Temperature (Operation)

-30°C to 70°C

Temperature (Stable Image)

0°C to 50°C

Assembly technique

SMT (ROSH)

Focus

Fixed

Object distance

30CM-infinity

Resolution

600LW/PH (Center)

PCB printing ink

Black

interface

USB 2.0

Power suuply

USB bus power

supply voltage

DC 5V±5%

Maximum Power consumption

920 mW

Operating system request

Win XP/win 7、8 / vista /android 4.0/ mac /Linux with uvc

Sensor

OV5693 (1/4” )

Seneor Package

PLCC,Bare Die

Maximum resolution

2592*1944

Sensitivity

780mV /（lux-sec）

Pixel Size

1.4µm x 1.4µm

Maximum Image Transfer Rate

MJPEG 640x480   30FPS /    YUY2 640x480   30FPS

MJPEG 1280x720  30FPS /    YUY2 1280x720  10FPS

MJPEG 1920x1080 30FPS /    YUY2 1920x1080  5FPS

MJPEG 2048x1536 30FPS /    YUY2 2048x1536  2FPS

MJPEG 2592x1944 30FPS /    YUY2 2592x1944  2FPS

S/N Ratio

36db

Max Dynamic Range

71.6db

Shutter type

Electronic rolling shutter

AGC/AEC/Whiter balance

Auto

Output Formats

YUY2/MJPEG

Microphone

Support

Lens Construction

2G2P

F/No

2.8

EFL

2.8mm

FOV

74°

TV Distortion

<8%

Relative Illumination (Sensor)

70%

IR Filter

650±10nm

Module Package

Anti-electrostatic tray

Certifications

FCC/CE/ROSH
