High Quality 2MP HD black & white binocular Blacklight Live HM2131(1/2.7'') Sensor CMOS Camera Module

product details
Module No.
HBVCAM-1821-2 V11
Module Size
68mm × 22mm × 17.4mm±0.5MM
Temperature (Operation)
-30°C to 70°C
Temperature (Stable Image)
0°C to 50°C
Assembly technique
SMT (ROSH)
Focus
Fixed
Object distance
30CM-infinity
Resolution
600LW/PH (Center)
PCB printing ink
Black
interface
USB 2.0
Power suuply
USB bus power
supply voltage
DC 5V±5%
Maximum Power consumption
2100mW
Operating system request
Win XP/win 7、8 / vista /android 4.0/ mac /Linux with uvc
Sensor
HM2131 (1/2.7” )
Seneor Package
CSP,Bare Die
Maximum resolution
1920*1080
Sensitivity
4600mv /(lux-sec)
Pixel Size
3µm x 3µm
Maximum Image Transfer Rate
MJPEG 320x240 30FPS / YUY2 320x240 20FPS
MJPEG 352x288 30FPS / YUY2 352x288 20FPS
MJPEG 640x480 30FPS / YUY2 640x480 20FPS
MJPEG 800x600 30FPS / YUY2 800x600 10FPS
MJPEG 1280x720 30FPS / YUY2 1280x720 10FPS
MJPEG 1920x1080 30FPS / YUY2 1920x1080 5FPS
FOV
100°
Certifications
FCC/CE/ROSH
