Best Quality 1.3 Mega Pixel HD Dual Lens 3D Synchronous Ov9750 (1/3 ) Sensor Interface Usb2.0 Cmos Camera Module

Module No.

HBV-1714-2 S2.0

Module Size

156mm × 36mm × 24.8mm±0.5MM

Temperature (Operation)

-30°C to 70°C

Temperature (Stable Image)

0°C to 50°C

Assembly technique

SMT (ROSH)

Focus

Fixed

Object distance

30CM-infinity

Resolution

600LW/PH (Center)

PCB printing ink

Black

interface

USB 2.0

Power suuply

USB bus power

supply voltage

DC 5V±5%

Maximum Power consumption

1450mW

Operating system request

Win XP/win 7、8 / vista /android 4.0/ mac /Linux with uvc

Sensor

OV9750 (1/3” )

Seneor Package

CSP,Bare Die

Maximum resolution

2560*960

Sensitivity

39.6ke /（lux-sec）

Pixel Size

3.75µm x 3.75µm

MJPEG 1280x480 60FPS / YUY2 1280x480 10FPS
MJPEG 1264x960 60FPS / YUY2 1264x960 10FPS
MJPEG 1280x720 60FPS / YUY2 1280x720 5FPS
MJPEG 1280x960 60FPS / YUY2 1280x960 10FPS
MJPEG 2560x720 60FPS / YUY2 2560x720 5FPS
MJPEG 2560x960 60FPS / YUY2 2560x960 5FPS

Output Formats

YUY2/MJPEG

FOV

91°

Certifications

FCC/CE/ROSH
